  • Brief introduction:
    4hp air-cooled diesel engine,diesel engine,diesel generator,Made in china,
  • E-mail: smart@kubaoya.com
  • Follow us:
  • Inquiry Now


ModelHR170FHR178FHR178FA
TypeSingle-cylinder,vertical,4-stroke air-cooled diesel engine
Combustion SystemDirect Injection
Bore×Stroke(mm)70×5578×6278×64
Displacement capacity(cc)211296305
Speed(rpm)300036003000360030003600
Horse power(hp)467
Max. output(kw)2.533.84.24.24.5
Rated output(kw)2.32.53.53.83.84.2
Fuelo# or-10# light diesel oil
Fuel oil tank volume(L)2.53.53.5
Lubricatiom oil volume(L)0.751.11.1
Fuel consumption rate(g/kw.h)≤285≤283≤285
Starting systemRecoil or Electric
PTO rotation directionIt is clockwise as viewing from the flywheel end
Dimension(mm)332×348×416383×412×450
Net weight(kg)283435

Advantages

♦ Economic and practical products from hi-earns,reliable performance.

♦ Choose hi-earns,choose a rest assured.

♦ Advanced production lines and test rooms.

♦ Complete system of IQC.

♦ Perfect QCP.

IQC

IQC

Strict spare parts IQC system, to ensure every spare parts are qualified.

Technical support in every step to eliminate all detailed questions.



Automatic Workshop

Modern workshops have advanced production lines and professional knowledge of assembly.

Flow card to record each details carefully.

Test engine at least twice before ex-factory.

Automatic Workshop-1.jpgAutomatic Workshop-2.jpgAutomatic Workshop-3.jpgAutomatic Workshop-4.jpg

Packaging Shipping

Strong packaging to ensure safty during transportation.

7 layer corrugated carton or wooden box packaging for products.



Companycertificates

Modern office building, we warmly welcome your visiting.

We attend exhibitions domestic and overseas. Rich activities to improve work enthusiasm.

ISO, CE, GS, Rohs certificates. We have been making good progress.
